WellRx “KRTY” Service Packers

The WellRx “KRTY” Compression-Set Service Packer is extremely versatile service packer designed to sustain the harshness of extreme well environments. It can be used in varied set of operations including testing, treating, and squeeze cement. KRTY Packer features locks on all internal connections, which allows the extreme torque to transmit.

Features

• Hold-Down buttons with higher OD reduces casing damage Sustenance to high torque allowing manipulation of RIH String/Drill Pipe.
• Availability of varied sizes.
• Smooth and simple operation.
• Higher hang-off weight supports due to heavy-duty mandrel.
• Standard connections.
• Torque transmission through rotationally locked end connections.
• Standard jay system.

Application

• Drill Stem Testing and production testing.
• Cement squeeze and treating operations.
• Storm packer applications.

WellRx “VIC” Storm Valve

The WellRx “VIC” Series Storm Valves is run above the KRTY service packer to isolate the tubing below the packer for disconnection during a weather emergency or surface equipment repair. The running string is disconnected by 15 left turns, and then the valve closes automatically. This quick, safe, cost-effective well closing requires no tubing pulling. The valve has an expandable plug that provides through-bore access for circulation or wireline passage. After the string is reconnected, the valve opens automatically to equalize pressure for packer retrieval.

Features:

• The rugged alloy-steel construction ensures dependability.
• The simple, field-proven design eases valve operation and redressing.
• The expandable plug provides through-bore access for circulation and wirelines.
• The valve equalizes automatically during string reconnection, enabling fast packer retrieval.

Application:

• BOP Repairs.
• Wellhead Repairs.
• Weather Emergencies.

WellRx “PID” Unloader Valve

The WellRx “PID” Unloader Valve is an associated tool for the WellRx KRTY Service Packer. The Equalizing Flow Valve is multifunction valve as it facilitates a way of equalizing tubing and annulus pressures as well as a bypass. In order to reduce the effect of fluid swabbing action when the equipment is run in or pulled out of the hole, a packer bypass is used. The valve has been designed to operate under harsh conditions.

Features:

• Backup rings on O-rings seal for high pressure and temperature.
• Standard connections.
• Right hand turn to open and right hand turn to close.
• Standard automatic jay mechanism.
• High-torque rating for manipulating heavy drill pipe into tight spots.
• Wide range of sizes available.
• Heavy-duty mandrel supports high hang-off weights.
• Smooth and simple operation.

Application:

• Drill stem and Production Testing
• HPHT Testing and Treating Operations.

WellRx “PHA” Series Retrievable Bridge Plugs

The WellRx “PHA” Series Retrievable Bridge Plug is a wireline set retrievable plug capable of holding pressure from above and below. PHA may be set on conventional wireline or hydraulic packer-setting tools. The short design is east to retrieve on tubing, coil tubing or sandline by using the appropriate retrieval tool. When the retrieving tool engages the top of the bridge plug, the equalizing valve opens before the bridge plug is released, preventing the bridge plug from moving with differential pressure.

Features:

• Wireline, Hydraulic or Coil Tubing Set.
• Caged Bi-Directional Slips.
• Equalizing valve opens before plug is released.
• Straight pull release.
• Overshot will wash to gauge ring for easy retrieval.
• Rotational safety release mechanism.
• Swab resistant packing element system.

Application:

• Acidizing, fracturing and cementing.
• Casing pressure testing.
• Wellhead repair or replacement.
• Zonal isolation.

WellRx “ATARP” Series Wellbore Cleanup Tools

Debris and residues left in the wellbore from drilling or production activities can result in reduced productivity or even significant non-productive time (NPT) for the operators. WellRx “ATARP” Series wellbore clean up tools are designed to maximize debris recovery from the wellbore and eliminate potential issues further into the well’s lifecycle.

Features:

• ATARP Casing Scraper
• ATARP Brush Tool
• ATARP Waste Retriever Tool
• ATARP Drift Sub
• ATARP Wellhead Jet Tool
• ATARP Jetted Bullnose
• ATARP Magnet Tool
• ATARP Flow Check Sub
• WellRx “KRTY” Service Packer
• WellRx “Equalizing Flow Valve”
