WellRx “AVAZ-D” Double Cone Hydraulic Set Non-Rotating Liner Hanger

AVAZ-D Hydraulic set Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well without rotating the work string to set the hanger. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Double cone solid body design with no welded part.
• The Hanger has two staggered row slip, each row has three set of slip.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Large By-pass area for free circulation.
• Can be set by hydraulic pressure within the string.

WellRx “EKAZ-S” Single Cone Hydraulic Set Non-Rotating Liner Hanger

EKAZ-D Hydraulic set Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for light to medium liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Single cone solid body design with no welded part.
• Used to Hang short to medium liner lengths.
• Recommended for highly deviated wells.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Can be set by hydraulic pressure within the string.

WellRx “AVAZ-R” Double Cone Hydraulic Set Rotating Liner Hanger

AVAZ-R Dual cone Hydraulic set Rotating Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for medium to heavy liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Solid body dual cone design with no welded part.
• Can be rotate after and during cementing job for better cement distribution.
• Roller bearing provide excellent compressive strength.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• No string movement required for hanger setting.

WellRx “PRAZ-C” Closed Slip Hydraulic Set Non-Rotating Liner Hanger

PRAZ-D Close Slip Hydraulic Set Non Rotating Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for medium to heavy liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Four set of Long and closed slip eliminates risk of premature setting.
• Special Slot and Edge design of slip provide uniform load distribution.
• Unique slip design provides maximum circulation area and clearance ratio.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Same design can be used from normal to special liner jobs.

WellRx “DRAZ-C” Super Grip Hydraulic Set Non-Rotating Liner Hanger

DRAZ-C Close Slip Super Grip Hydraulic Set Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for medium to heavy liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Two set of Short and closed slip provides excellent grip.
• Each set contain three slip staggered design.
• Special Slot and Edge design of slip provide uniform load distribution.
• Unique slip design provides maximum circulation area and clearance ratio.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Same design can be used from normal to special liner jobs.

WellRx “CIAZ-D” Double cone Hydraulic Set Non-Rotating Integral Liner Hanger

CIAZ-D Integrated Hydraulic Set Liner Hanger is combination of Liner hanger and Liner Top Packer available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well without rotating the work string to set the hanger. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Double cone solid and Single body design with Integral Top packer no welded part.
• The Hanger has two staggered row slip, each row has three set of slip.
• Packer is available with different packing and grip arrangements.
• Elements of packer designed with improved By-pass area for free circulation.
• Can be set by hydraulic pressure within the string.

WellRx “CIAZ-C” Closed Slip Hydraulic Set Non-Rotating Integral Liner Hanger

CIAZ-C Closed Slip Hydraulic set Integrated packer is combination of Liner hanger and Liner Top Packer available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well without rotating the work string to set the hanger. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Four set of Long and closed slip eliminates risk of premature setting.
• Special Slot and Edge design of slip provide uniform load distribution.
• Packer is available with different packing and grip arrangements.
• Elements of packer designed with improved By-pass area for free circulation.
• Single body deign reduce cost and save time while makeup.

WellRx “EKAZ-R” Single Cone Hydraulic Set Rotating Liner Hanger

EKAZ-R single cone Hydraulic set Rotating Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for medium to heavy liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Solid body single cone design with no welded part.
• Can be rotate after and during cementing job for better cement distribution.
• Roller bearing provide excellent compressive strength.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• No string movement required for hanger setting.

WellRx “CIAZ-R” Double Cone Hydraulic Set Rotating Integral Liner Hanger

CIAZ-R Double cone hydraulic set rotating liner hanger with integrated packer is combination of Liner hanger and Liner Top Packer available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well without rotating the work string to set the hanger. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Double cone solid and single body design with Integral Top packer no welded part.
• The Hanger has two staggered row slip, each row has three set of slip.
• Packer is available with different packing and grip arrangements.
• Elements of packer designed with improved By-pass area for free circulation.
• Can be rotated after setting for better cementing.

WellRx “PRAZ-R” Closed Slip Hydraulic Set Rotating Liner Hanger

PRAZ-R Close Slip Hydraulic Set Rotating Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for medium to heavy liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Four set of Long and closed slip eliminates risk of premature setting.
• Special Slot and Edge design of slip provide uniform load distribution.
• Unique slip design provides maximum circulation area and clearance ratio.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Can be rotated after setting for better cementing.

WellRx “CIAZ-CR” Closed Slip Hydraulic Set Rotating Integral Liner Hanger

CIAZ-CR Closed Slip Closed Slip Hydraulic set rotating Liner Hanger with integral Packer combination of Liner hanger and Liner Top Packer available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well without rotating the work string to set the hanger. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Four set of Long and closed slip eliminates risk of premature setting.
• Special Slot and Edge design of slip provide uniform load distribution.
• Unique slip design provides maximum circulation area and clearance ratio.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Can be rotated after setting for better cementing.

WellRx “AVAZ-M” Double Cone Mechanical Liner Hanger

AVAZ-M Mechanical set Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well with combination of rotation and compression to set the hanger. The mechanical liner hanger is recommended for applications such as high deviation encountered.

Features

• Double cone design with special J-mechanism for easy setting.
• The Hanger has two staggered row slips, each row has three set of slip.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Large By-pass area for free circulation.
• No hydraulic pressure required throughout the operation.

WellRx “EKAZ-M” Single Cone Mechanical Liner Hanger

EKAZ-M Mechanical set Liner Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used to hang a liner in well with combination of rotation and compression to set the hanger. The mechanical liner hanger is recommended for applications such as high deviation encountered.

Features

• Single cone design with special J-mechanism for easy setting.
• Short length design facilitates easy run with short length liners.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Large By-pass area for free circulation.
• No hydraulic pressure required throughout the operation.

WellRx “CIAZ-E” Closed Slip Equilibrium Feature Hydraulic Set Non-Rotating Liner Hanger

CIAZ-E Close Slip Equilibrium Piston Hydraulic Set Liner Hanger is special hanger used where high circulation required clearing tight spots. Hanger is available in most combination of Liner to casing size, materials and thread combinations commonly used for medium to heavy liner jobs. The hydraulic liner hanger is recommended for applications such as setting new liner through existing liners or on floating rigs.

Features

• Four set of Long and closed slip eliminates risk of hanger stuck situation.
• Special design permits high circulation rates through string.
• Hanger can be available with all combinations (Non-rotating, Rotating).
• Unique slip design provides maximum circulation area and clearance ratio.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing

WellRx “VYAZ-D” Hydraulic set Non-Rotating Low Clarence Liner Hanger

VYAZ-D Hydraulic set non rotating Low Clarence Liner Hanger is specially design hanger used where very low Clarence available for hanger running in and setting.

Features:

• Special Slim Design slips for very low Clarence.
• Elimination of long slip arms reduces risk of pre-mature setting.
• Hanger can be set without string movement.
• Hardness controlled slips assure their biting and hanging capacity even in the highest strength casing.
• Hanger can be supplied with nonstandard liner casing combination.

WellRx “HF-1” High Flow Liner Top Packer

HF-1 High Flow Liner Packers provide an excellent secondary seal that can be used to control annular gas migration or protect sensitive zones from well hydrostatics after cementing. These Liner Packer can run with conjunction of Wellrx model Liner Hangers.

Features:

• Compression set by applying weight through TBR.
• Flow assisted design Packing Element.
• Large By-pass area for free circulation.
• No hydraulic pressure required throughout the operation.

WellRx “HF-SG” High Flow Super Grip Liner Top Packer

HF-SG High Flow Super Grip Liner Packers provide an excellent secondary seal that can be used to control annular gas migration or protect sensitive zones from well hydrostatics after cementing. These Liner Packer can be run independently as set on bottom liner Packers, as the top pack off on a scab liner run and with conjunction of Wellrx model Liner Hangers. Equipped with Hold down Slips

Features:

• Compression set by applying weight through TBR.
• Flow assisted design Packing Element.
• Large By-pass area for free circulation.
• No hydraulic pressure required throughout the operation.
• Equipped with Slips and Lock ring to lock applied forces

WellRx “AYAT” Polish Bore Receptacle

AYAT Polish Bore Receptacle has a honed polish seal bore which is used to tying in to liner with WELLRX tie back seal mandrel or by Tie Back Packer. The PBR also provides the extension which is later used for setting liner top packer. It is also used for protecting the running tool assembly during running in of hook-up in the hole. By using junk screen it can also enhance the debris protection system

Features:

• Throughout honed ID provide reliable seal bore
• Act as shield for running tool.
• Threaded with Liner Top Packer
• Length available from 6ft to 20ft

WellRx “AVDO” Setting Sleeves

“AVDO”-Series Setting Sleeves are designed to run with WellRx Liner Hanger. They typically run above the Liner hanger and serves several purpose depending on the operation and equipment requirement.

Features:

• Carrying Liner Load during the job.
• Serve various purposes like carrying tool, running tool engagement, and Liner rotation.
• Made with equivalent grade of steel material.
• ID typically matches with Liner ID

WellRx “VIPAM” Tie Back Seal Mandrel

WELLRX “VIPAM”-series Tie Back Seal Mandrel is an economical and efficient liner Top isolation tool. It is used on most vertical well application. It can be used to run the entire liner length up to surface and cementing.

Features:

• Easy to operate
• Seals are provided in stacks.
• Can be ordered in different length depending upon Polish Bore receptacle length
• Provide full opening as ID is equal to Liner ID

WellRx “VISAM” Tie Back Packer

“VISAM” series Tie Back Mechanical Packer is an economical and efficient liner Top Tie- Back Packer. It is used on most vertical well application. It can be used as Liner Top isolation Packer in case of annulus leakage. This packer is used to tie back casing to the surface when existing casing develops leaks or is damaged.

The tie back seal mandrel, seals into the polished bore receptacle of an existing liner. The seal mandrel engages in the tie back receptacle and provides a pressure competent sealing. The seal material is available for different well environment conditions. The Seal O.D is compatible with Tie back Receptacle. The bottom mule shoe has circulation ports for circulation and cementing as and when required

Features:

• Weight set
• Seals are provided in stacks.
• Can be ordered in different length depending upon Polish Bore receptacle length
• Provide full opening as ID is equal to Liner ID

WellRx “TAZR” Landing Collar

WellRx “TAZR” Landing Collar provides Latch down seat and seal for the liner wiper plug, and provides an additional back up to the float collar and / or shoe to ensure that cement remains in place after displacement. The landing collar is normally run one or two joints above the float shoe or just above the float collar. 6061- T6 aluminum alloy is used internally for easy drill ability.

Features:

• Used with Hydraulic and Mechanical Liner hangers.
• 6061- T6 aluminum alloy is used internally for easy drill ability.
• Act as additional back-up during cement job.
• Field adaptable design.

WellRx “AST-F” Double Valve Super Seal Float Shoe with Side Ports

WellRx Cement / Non Cement / Plunger Type / ball-type / Aluminum Valve type float equipment offers dependable performance for all classes’ oil and gas wells. The valves prevent cement backflow, provide casing buoyancy during run in, and act as internal BOPs during the process of running and cementing the casing.

Features:

• Dual spring loaded valve, assembled in tandem.
• Angular side port for smooth and uniform flow
• Tested at 10BPM
• PDC drillable
• Made up with matching grade of steel and Liner threads
• Available with different design and configuration

WellRx “AST-R” Double Valve Super Seal Reamer Shoe with Side Ports

WellRx Cement / Non Cement / Plunger Type / ball-type / Aluminum Valve type reamer shoe offers dependable performance for all classes’ oil and gas wells. The valves prevent cement backflow, provide casing buoyancy during run in, and act as internal BOPs during the process of running and cementing the casing and act as guide shoe which can able to clear the restrictions and tight spots.

Features:

• Dual spring loaded valve, assembled in tandem.
• Angular side port for smooth and uniform flow
• Tested at 10BPM
• Slots over body facilitate to take up cuttings while clearing tight spots.
• Shoe body welded with carbide to clear tight spots while rotating.
• Made up with matching grade of steel and Liner threads
• Available with different design and configuration

WellRx “SABH-1” Mechanical Running Tool

The WellRx SABH-1 MECHANICAL RUNNING TOOL is designed to run and set a liner. A set of spring loaded dogs can be added to the standard tool so that liners equipped with weight set liner packers on top, can also be run and set in one go.The Bottom Connection of the SABH-1 MECHANICAL RUNNING TOOL setting has an 8 Round connection to allow any of the four types of cementing pack-off assemblies to be utilized. A splined floating nut with external left hand acme threads is made up in the liner setting sleeve or liner packer and carries the liner assembly into the hole. A ball bearing assembly above the floating nut supports the weight of the run in string while the setting tool is being released with right hand rotation from the liner setting sleeve or liner packer.

Features:

• Used to run left-hand set mechanical and hydraulic set hangers
• Ball bearing race/floating nut system ensures positive release from liner top
• Drill pipe thread at top
• Accepts all types of cementing pack-Off assemblies
• Optional packer setting dogs incorporated in main body
• Full strength mandrel to carry long, heavy liners to depth
• Setting tool is released with right hand rotation, therefore, less danger of backing off the drill pipe

WellRx “AYABH” Hydraulic Release Running Tool

The WellRx AYABH series Hydraulic Release running Tool is used to run and set the liner hanger with or without Liner Top Packer. The Running Tool is made with Setting Sleeve & assembly is run on drill string to the bottom. The Hydraulic Release Drilldown Liner Setting Tool connects to the Liner Setting Sleeve profile provides a means to carry a liner down hole, set a liner hanger and release from the liner prior to or, if desired, after cementing. The primary releasing mechanism is hydraulic with an emergency mechanical back-up release system. This tool carries the weight of the liner on a fully supported collet assembly with no threads that could back off and drop the liner while running in the hole. High torque ratings of the Hydraulic release Running Tool system al-low aggressive rotation if required to work a liner to bottom.

Features:

• No string manipulation required to release the tool
• Equipped with mechanical emergency release
• Tool support extended reach operation
• Back up mechanism present in case tool release mechanically accidently
• Compact and robust design

Other Accessories

Features:

• Cup Tool
• Handling Joints
• Junk Bonnets
• Pack-Off
• Retrievable Pack-Off
• Extrudable Ball Seat
• Tubing Swivel
• Plug Swivel
• Slick Stinger
• Liner Plugs
• Drill Down darts
• Ported Sub
